ELM327 V1.5 USB Scanner Wireless Interface Auto Interface Code Readers Diagnostic OBDII Protocols

Features: - V04HU-1 is the newly developed wireless scan tool. It supports most standard OBD-II protocols - Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database) - Clear trouble codes and turn off the MIL ("Check Engine" light) Language: English Product Name: OBDII Model Name: V04HU-1 Hardware Version: V1.5 Communication Mode: USB Chip: ST Support: Windows Working Voltage: 9V-16V Working Current: 15mA Standby Current: 0mA Interface: 16Pin Working Temperature: - 40 ~ 85 Working Humidity: Less than 60% OBD2 Protocols: Support Almost OBD-II Protocols Function: Code Reader Diagnosis OBDII Support Agreement: - SAE J1850 PWM (41.6Kbaud) - SAE J1850 VPW (10.4Kbaud) - ISO9141-2(5 baud init, 10.4Kbaud) - ISO14230-4 KWP (5 baud init, 10.4 Kbaud) - ISO14230-4 KWP (fast init, 10.4 Kbaud) - ISO15765-4 CAN (11bit ID, 500 Kbaud) - ISO15765-4 CAN (29bit ID, 500 Kbaud) - ISO15765-4 CAN (11bit ID, 250 Kbaud) - ISO15765-4 CAN (29bit ID, 250 Kbaud) Display Current Sensor Data, Including: - Engine RPM - Calculated Load Value - Coolant Temperature - Fuel System Status - Vehicle Speed - Short Term Fuel Trim - Long Term Fuel Trim - Intake Manifold Pressure - Timing Advance - Intake Air Temperature - Air Flow Rate - Absolute Throttle Position - Oxygen sensor voltages/associated short term fuel trims - Fuel System status - Fuel Pressure - others. Compatible Software: - Windows Version: Scanmaster-elm, ScanTool.net, PCMSCAN, etc. Compatible Platform: - Software support platform: Windows XP, Windows 7/8, etc. Package Weight : 25 G / 0.88 Ounces Package Dimensions (L*W*H) : 66*26*100 MM / 2.60*1.02*3.94 Inches Retail Packaging: No, No Packing

Package Include: 1 x Host
