Maximum IR Distance(m) : 10-20m
Certification : CE
Lens : 2.8mm
Origin : CN(Origin)
Sensor Size : 1/3 inch
Model : IPC-5200 Plus
4K H.265/H.264,8MP TVI, 8MP CVI, 8MP AHD, 8MP EX-SDI IP Camera Tester
Features
Camera test:
— 5 inch IPS touch screen, 1920*1080 resolution
— H.265 & H .264 IP, 4K video display via mainstream
— 8MP TVI test,3840 x 2160P 12.5/15 FPS,4xzoom ,video record & playback ,coaxial PTZ control & call OSD menu *
— 8MP AHD test, 3840x2160P 15 FPS, 4xzoom, video record & playback, coaxial PTZ & call OSD menu *
— 8MP CVI test, 3840 x 2160P 12.5/15FPS, 4xzoom, video record& playback, coaxial PTZ & call OSD menu *
—8MP EX-SDI test, 3840 x 2160P 25/30FPS, coaxial PTZ & call OSD menu*
—HD-SDI, 3G-SDI test, 1920 x 1080P 25/30/50/60 FPS, coaxial PTZ & call OSD menu*
— Rapid ONVIF, Auto log in and display image, create testing report
— IPC TEST (Non-ONVIF test)
— CVBS camera test, PTZ controller
— DC12V/3A power output, camera can be powered from DC 12Votage
— Built in Wi-Fi, display image from the wireless camera, create WIFI hotspot
— Color bar generator, PAL/NTSC multi-system color bar video generator
Cable test:
— Improvement cable tester, UTP cable, telephone cable etc order and connectivity test, save testing report
— RJ45 cable TDR test, test cable pair status, length, attenuation, reflectivity, impedance, skew etc
Other Functions:
— Network tool: Ping, IP scan, Port Flash ,DHCP server, Trace Route
— POE & power information, DC12V & PoE power and voltage output /input measurement
— TesterPlay: Tester, android mobile phone and PC display at the same time
—VGAinput, up to 2048 x 1152 60FPS*
— HD signal input, support 4K 30FPS*
— Traffic monitoring of the tester "LAN port", display upload and download speeds
— Customers self-update software, you can install apps with android version
— 7.4 V /3350mAh Lithium Ion Polymer Battery, after 3~4 hours charging , working time lasts 6 hours
