Description
• Wireless CarPlay and Android Auto: Connect your phone wirelessly to your car's infotainment system and enjoy seamless integration with your favorite apps.
• Portable and Foldable: Have fun on the road with this portable and foldable screen that can be easily stored in the car.
• Bluetooth and Auxiliary input: Connect your phone to your car's audio system via Bluetooth or auxiliary input to get high-quality audio.
• FM Transmitter: The built-in FM transmitter allows you to transfer music from your phone to your car's audio system, making it easy to enjoy your favorite tunes on the road.
• Processor: F133
• RAM: 1 GB
• Display resolution: 1280x480
• Screen size: 6.86 inches
• Radio transmission frequency:88.60、89.50、91.50、93.00、93.90、95.10 Additional frequency range 87.5~108.0MHz
•Radio transmitter chip: AB5301B
• Bluetooth version: 5.0 (default name: SWL-BT)
Format Parameters
Audio format: MP3 /AAC/APE/OGG/M4A/RA/WAV
Video format: H263 / H264/H265 / DIVX HD /AVI/FLV /MKV/MPEG/MP4/WMV9/VC/ASF/TS/QT
Image format: JPEG/PNG/BMP/GIF/TIFF
Functional parameters
Mobile phone connection: support
Reverse image: support
Video Playback Warning: Support
DVR for driving: support
Built-in speaker: support
TYPE-C interface: support
TF card: support
Questions and answers
Q: How do I connect carplay and Android car?
A: Find the Bluetooth device "SWL-BT" on your mobile phone. When you connect it for the first time, a prompt will appear on your mobile phone, please click to use the device or trust it.
Question: How do I connect a mirror link?
A: Before connecting the phone, click on the phone connection function of the device, change the automatic connection option in the corresponding phone type to mirror, then connect the phone data cable and click the appropriate authorization on the end of the phone to connect.
Q: How do you transmit sound through a car horn?
A: There are three comments about the sound problem:
1. Our device comes with a small speaker that can make sound, you can turn it off
by installing; 2. Transmit the sound to the original car radio via
The FM transmission function of the device (for example, select 86.3MHz on
on the device, and then play music from the U-disk, then search for 86.3 MHz on the car radio);
3. Use a 3.5mm AUX cable to transfer audio to the original carplayer
via the AUX OUT interface of the device (some models do not support this function, please see the product interface description for details).
Q: Bluetooth connection failed, or are some functions not working properly after connection?
A: Please use your mobile phone to search for a Bluetooth device named "carplay"; Delete the devices that were paired but not connected to the phone. Some Bluetooth devices that have been paired with each other may make it impossible to pair the Bluetooth phone with other devices or disrupt its function.
Q:
Does Bluetooth connect to carpaly or Android auto automatically?
A: 1. Some connected Bluetooth devices will cause our device to be unable to switch
automatically. Please clear all paired Bluetooth devices on your mobile phone,
restart the Bluetooth of the mobile phone and the car device and reinstall
Bluetooth connection. 2. Click on the interface and make sure that the carplay switch is on
it is in the "carplay" position. 3, click "Settings" - "Basic Settings" - "Restore factory settings".
Q: Are music playback and phone conversations too quiet?
A: Hold the top of the screen with your finger and swipe down. You can adjust the playback volume by pulling down the status bar; When you return to the home screen during a conversation, you can adjust the call volume in the status bar.
Question: Can't you remember the time and date?
A: Due to the high temperature in the car in summer, in order to ensure safety, the device does not have a battery, so it cannot remember the time and date. After connecting the mobile phone, it will automatically update the time and date.
Q: Can't read or play music and videos from SD cards, USB drives?
A: Please use an 8GB or 16GB memory card or a USB flash drive. Some high-capacity storage devices may not support it. Format the storage device to make sure that the file system of the storage device is the default value; Partially encoded video or music may not be recognized by the device, please use media files of a common format.
Question: Touch screen
It doesn't work properly
A: Long press with five fingers on the touch screen, after a few seconds to enter the touch correction interface, press the crosshair on the screen to restore.
Report incorrect example or translation
The package contains:
1.Host
2.User's Guide
3.The power cord from the cigarette lighter
4.Reverse video cable
5.TYPE-C to USB adapter cable (Accessories, instructions and packaging will be updated from time to time depending on the actual receipt)
