Feature:
1. Designed with high definition LCD screen, offers clear and bright display from every angle.
2. Monitoring the battery capacity and voltage by this mini tester.
3. Easy to read the value in dark environment with the blue backlight.
4. Widely used for car, motorcycles, scooters, bikes, power bank, test equipment, etc.
5. For checking the remian capacity of batteries, diretly display with battery capacity sign and percentage.
6. The instrument has the characteristics of accuracy and stability, small size, easy to carry.
7. Pro Version: Professional version with temperature detection and low pressure alarm function （Temperature + alarm version）
Specification:
Condition: 100% Brand New
tem Type: Battery Monitor
Material: ABS
Dispaly Color: multicolour
Voltage Measurement Range: DC8V-100V
Working Current: <15MA
Measurement Accuracy: 1% ± 1 word.
Display: LCD screen
Measurement Speed: about 2 times per second.
Dimensions: Approx.6.5x3.5x1.5cm / 2.6x1.4x0.6in
Installation Size: Approx.58x28mm / 2.3x1.1in
Lead Length: 20cm / 7.9in
Product Manual:
1. Ternary lithium battery L measurement from L02 string to 25 strings. Power off with memory.
2. Lead-acid battery P measurement can be from DC12V to DC24V, DC36V, DC48V, DC60V, DC72V, DC84V. Power strip memory
3. Iron lithium battery pack F can measure F03 string to 26 strings. Power strip memory
(If you need detailed setup instructions, please contact us)
Package included:
1 * Battery capacity indicator (3 optional)
1 * cable lead
