Features:
High Definition IPS Screen: Wide color gamut IPS screen and 1280x800 high resolution ensure the monitor more precise color restoration, exquisite picture quality and more rich color.
Wider Viewing Angle: The IPS panel of the camera field monitor provides a wide 178 degrees / 178 degrees ? viewing angle and 400nit brightness output. This means you will be able to see accurate, consistent and bright images from any point of view.
Slim and Lightweight Design: Special designed to merge portability and functionality, this camera video monitor is only 17mm in thickness and 400g net weight, to give you the freedom to record well anywhere, to check your picture accurately, consistently and clearly.
Support a Wide Range of Signal Inputs: The camera field monitor has multiple inputs including HDMI and AV, and also supports most DSLRs and camcorders.
Advanced
Features: The camera field monitor supports multiple advanced functions, such as peaking focus assist, check field(red, green, blue, mono), image flip, screen marker, centre marker, 4:3/ 16:9 image adjustable, pixel-to-picel, image freeze.
Specifications:
Screen Size: 7 inch IPS
Resolution :1280*800 pixels
Point Distance: 0.11775(H) * 0.11775(V) mm
Screen ratio: 16:10
Brightness: 400cd/m2
Contrast: 800:1
Backlight: LED
Viewing Angle: 89 degrees /89 degrees (L/R) 89 degrees /89 degrees (U/D)
Input: HDMI, AV, OSD
Output: 3.5mm headphone interface, speaker
Input Voltage: DC5.5-35V
Power Consumption: less than 5W
Power interface: DC
Battery Board: F970 (standard)
Operating temperature: -20 celsius to 50 celsius
Storage temperature: -30 celsius to celsius
Product size: 176Lx130Hx17D (mm)
Product weight: 300g
Package List:
1 x Camera Monitor
1 x Sunshade
1 x Mini Ballhead Adapter
1 x F970 Battery Board
1 x Cable Lock
1 x Users Manual(English)
