Feature:
1. When the multi?function current and voltmeter is measuring, the circuit takes power from the power input port, and no additional power cord is required.
2. The LCD screen display can display information such as voltage, current, power, discharge mAH, discharge time and working temperature.
3. The protection mechanism is complete, with under?voltage protection, overvoltage protection, overcurrent protection, overpower protection, overtemperature protection, overtime protection and overcapacity protection.
4. By setting appropriate undervoltage protection and overvoltage protection thresholds, the battery overcharge and overdischarge control functions can be realized.
5. Timed and quantitative battery charging and discharging can be realized by setting appropriate overtime protection and overcapacity protection thresholds.
Specification:
Condition: 100percent Brand New
Item Type: Multifunction VoltAmmeter
Material: Plastic Housing
Product Size: Approx. 79 x 42 x 26mm3.1 x 1.7 x 1in
Model
ZKU15
Input Voltage
DC 5V38V(With AntiReverse Connection)
Input Current
0.03A5.00A
Operating Current
<=30mA
Voltage Accuracy
(+1percent +1 Word)
Accuracy of Current
(+1percent +1 Word)
Working Environment Temperature
15 celsius 50 celsius
LVP Threshold of Undervoltage Protection
4.8V by Default (Adjustable between 4.8V38V)
OVP Threshold for Overvoltage Protection
Default 38.0V(Adjustable between 4.8V38.0V)
OCP Threshold for Overcurrent Protection
Default 5.5A (Adjustable between 0.5A5.5A)
OTP Threshold of Overtemperature Protection
80 celsius (Adjustable between 40 celsius 80 celsius )
OCP Threshold for Overcurrent Protection
Default 5.5A (Adjustable between 0.5A5.5A)
OPP Threshold of Overpower Protection
Default 200W(Adjustable between 1W200W)
Detailed Product Function:
1. LCD screen display
In the normal mode, the LCD screen displays the input voltage and working temperature in the upper; the lower displays the realtime current, power, capacity and discharge time. In the protection mode, the LCD screen displays the protection codes.
In the setting mode, the LCD screen displays each setting parameter codes and parameter threshold.
2. Sound and light alarm
When the voltage and current meter output is turned on, the RUN indicator light is always on and the buzzer does not sound; when it is turned off, the RUN indicator light does not light, and the buzzer does not sound. After entering the protection mode, the buzzer will alarm and the RUN indicator will flash.
3. Automatic statistics of charge and discharge capacity and time. As long as the output is turned on (the RUN indicator is always on), the statistics will be started, and the output will be turned off (the RUN indicator is not on), and the statistics will be stopped. In the interface, long press the buttonthe corresponding data can be cleared. Start
Before statistics, please clear the statistics data to 0. The maximum discharge capacity (OAH) and maximum discharge time (OHP) can be set on or off in the setting mode (default off). After being turned on, the threshold value can be set. If the threshold value is exceeded, the output will be automatically turned off and the buzzer will alarm to achieve no Charging and discharging the battery on duty.
4. By setting appropriate overvoltage protection threshold and undervoltage protection threshold, battery overcharge and overdischarge control can be achieved. For detailed operation, please refer to the product application example.
5. Complete software and hardware protection mechanism, and the software protection threshold can be adjusted. After software protection, the output is turned off.
Hardware Protection:
The input port of the module has antireverse connection protection, and the reverse connection will not burn.
Software Protection:
OVP overvoltage protection (default 38V, can be set by yourself, after overvoltage protection, the RUN indicator flashes, and the LCD interface displays OVP. During battery charging, setting a proper threshold can effectively prevent battery overcharging);
OCP overcurrent protection (default 5.5A, can be set by yourself, after overcurrent protection, the RUN indicator flashes, and the LCD displays OCP);
OPP over power protection (default 200W, can be set by yourself, after over power protection, RUN indicator flashes, LCD shows OPP);
Steps for Usage:
1. First connect the battery and load, and check whether the wiring is correct.
2. The voltage and current meter enters the normal interface. If it is not in the normal interface, short press the ON button to return to the normal interface.
3. Long press the ON button to enter the setting interface, and SET is displayed in the lower left corner of the LCD screen.
4. Short press the SW key to switch the parameters to be set. Short press + orto increase or decrease the parameter by 1. Long press + orto continuously increase or decrease the parameter. In the battery discharge application, the OVP needs to be adjusted above the maximum battery voltage, the maximum is 38V. Adjust LVP to the lowest voltage allowed by the battery (this voltage needs to refer to the parameters in the battery manual). Generally, the minimum discharge voltage of a 12V lithium battery is 9.2V. The minimum discharge voltage of a 24V lithium battery is 18.5V.
5. Long press the ON button to exit the setting mode.
6. Short press the ON button, the indicator light is always on, the output is turned on, and the battery starts to discharge.
7. If the battery voltage drops to the value set by LVP, the output is turned off, the battery stops discharging, and the LCD screen displays LVP, indicating that the indicator light flashes and the buzzer alarms.
8. If you need regular discharge or constant capacity discharge, you can set OHP (timing) or OAP (constant capacity) parameters in the setting mode. Setting steps: In the setting interface, short press the SW key to switch to the OHP or OAH interface. Short press the ON button to turn on the timing or constant capacity function, and the LCD interface will change from OFF to digital. Press + orto adjust the parameter size. After setting the parameters, long press the ON button to exit the setting interface. When the time or capacity reaches the set value, the output is turned off and the discharge is stopped, the LCD screen displays the OHP or OAP codes, the indicator light flashes, and the buzzer alarms..
Package List:
1 x VoltAmmeter1 x English Manual
Note:
Please read the manual carefully before using this product!When the multi?function current and voltmeter is measuring, the circuit takes power from the power input port, and no additional power cord is required.
The LCD screen display can display information such as voltage, current, power, discharge mAH, discharge time and working temperature.
The protection mechanism is complete, with under?voltage protection, overvoltage protection, overcurrent protection, overpower protection, overtemperature protection, overtime protection and overcapacity protection.
By setting appropriate undervoltage protection and overvoltage protection thresholds, the battery overcharge and overdischarge control functions can be realized.
Timed and quantitative battery charging and discharging can be realized by setting appropriate overtime protection and overcapacity protection thresholds.
