Joom: Safely charging your e-bike or e-scooter
• Don’t leave your battery unattended while charging, when you're out or while you're asleep
• Don’t cover chargers or battery packs when charging
• Don’t overload sockets or use unsuitable extension chords
• Don’t charge or store batteries in direct sunlight or in areas with temperatures above 45⁰C
• Don’t charge batteries next to combustible materials or hazardous substances
• Always unplug your charger once you have finished charging
• Always make sure to only use the proper proprietary charger
• Always ask a professional when converting your e-bike or e-scooter
• Always check your battery (and charger) for visible damage
-----
Highlights：
1600W*2 High-Performance Dual-drive Motor
Kukirin G4 MAX is equipped with 60V/1600W*2 motors, it can provide powerful power and torque, making acceleration and climbing easier. The maximum speed can reach 86km/h, which makes it a very fast and exciting electric scooter.
Removable Lithium Battery
The 60V/35.2Ah lithium battery has a range of 95km, which can meet the travelling needs of most people. The removable lithium battery design makes it easy to remove and install the battery, making it convenient for users to charge or replace the battery at any time.
Multifunctional Intelligent Display
The multi-functional intelligent display integrates multiple functions, including speed display, battery indicator, fault diagnosis, mileage recording, etc. Supports a variety of personalized settings, such as backlight brightness adjustment, startup mode adjustment, etc., to meet the usage habits and needs of different drivers.
Front & Rear Four-piston Oil Brakes
The front and rear four-piston oil brakes realize braking through the principle of hydraulic pressure. They have the characteristics of stable braking performance, fast response speed, good heat dissipation performance and short braking distance. They can effectively cope with emergency braking situations at high speeds and provide drivers with Provides safer driving guarantee.
Fast Charging
The dual charging port design allows drivers to charge the battery with two chargers at the same time, saving charging time and improving charging efficiency and convenience.
Cool Lighting System
High-brightness LED headlights, taillights, and turn signals combined with cool ambient lights not only provide good lighting, but also ensure driving safety.
Front & Rear Dual Hydraulic Damping Shock Absorption
The front and rear hydraulic damping and shock-absorbing systems can better cope with bumps and uneven road surfaces, reducing the impact on the driver and providing a smoother and more natural driving experience.
12-inch Off-road Pneumatic Tire
12-inch ultra-wide off-road pneumatic tires have wider treads and off-road tread patterns, which can provide better grip and traction, shock absorption and buffering effects, absorb vibrations caused by uneven road surfaces, and improve driving comfort.
Specification：
General
Brand: Kukirin
Type: Electric Scooter
Model: G4 Max
Specification Frame material: Aluminium alloy
Speed: 36km/h 66km/h 68km/h (single drive), 38km/h 70km/h 86km/h (dual drive)
Mileage: 95km
Climbing ability: 38°
Brake system: Front and rear piston oil brake
Brake distance: 6-8m
Waterproof grade: IP54
Motor: 1600W (2000W Max)
Max output torque: 41N.M
Battery: 60V 35.2AH
LED headlight: 2*6W
Front shock absorber: Hydraulic upside-down shock absorber
Rear shock absorber: Hydraulic shock absorber
Tire: 12-inch off-road pneumatic tires
Input voltage: AC200-240V~50/60Hz
Input current: 5A
Output voltage: 67.2V
Output current: 5A
Max load: 150kg
Weight & Size Product Weight: 64kg
Package Weight: 78kg
Product Size(L x W x H): 1425*640*1340mm
Package Size(L x W x H): 1470*350*750mm
Package Contents
1 x Electric scooter
1 x Bag
1 x Toolbag
1 x Inflator bump
1 x Charger
1 x User Manual
