Product Support Platform
1. PC (Windows7/8/10/11)
2. Switch (including Switch lite, Switch OLED, and Hong Kong, Japanese, and Chinese versions)
3. iOS devices (iOS system must be IOS16 and above)
4. Android devices (Android 8.0 and above)
Product Connection Method
Triple-mode Link: Bluetooth + 2.4G Receiver + Data Cable
Contrroller Parameters
Joystick: Hall Joystick
POM Ring: Yes
Report Rate: Wired 1000Hz / 2.4G 1000Hz / Bluetooth 125Hz
ABXY: Conductive Glue
Shoulder Button: Touch Switch
Trigger Button: Hall Linear Trigger
Trigger Lock: Can Physically Switch Linear Trigger or Wireless Trigger
Cross Button: Pot + Silicone Pad
4 Auxiliary Buttons + FN Button: Touch Switch
4 Back Buttons: Touch Switch
Gear Switch: Receiver / Bluetooth / Switch
Motor: Asymmetric rotor motor
Battery: 1000mAh
APP: PXN NEXUS
Body sensing: Support
Switch one-button wake-up: Support
NFC: Not supported
Bluetooth version: 5.2
Product selling points
1. High-life Hall magnetic induction joystick, new algorithm to avoid drift
2. Hall linear trigger, 256-level travel
3. Support wired, Bluetooth and 2.4G multi-mode connection, compatible with four major platforms: PC, switch, Android, and iOS
4. Support Bluetooth BLE to connect to mobile phones, use APP for configuration
5. APP visual programming, multiple parameters stepless adjustment
6. APP can map buttons, set button bursts, swap joystick cross keys, adjust joystick dead zone, etc.
7. FN key supports handle adjustment function, set bursts, macro recording
8. Support grip vibration, APP The internal motor can be adjusted separately
9. Built-in six-axis gyroscope, supports somatosensory
10. Supports one-click wake-up of NS host
11. Two-stage trigger lock, one-click switch trigger wireless mode
12. The handle has 4 back buttons, which can map individual keys or record macro parameters
